- Integrated with myViewBoard software
- Multi-tasking capabilities for enhanced lesson delivery
- Embrace simplicity and organization with the USB-C one-cable solution, offering 65W of Power Delivery.
- Intuitive user interface and fast app launch for smooth operation
- Powered by Android 11
ViewBoard IFP6533-G. 290,000.00/=
ViewBoard IFP7533-G 330,000.00/=
ViewBoard IFP8633-G. 500,000.00/=
Specification
| Display Details | ||
| Display Format Native Resolution | 4K UHD 3840×2160(Pixels) | |
| Aspect Ratio | 16:9 | |
| Picture Response Time | 6ms | |
| Display Colors | 1.07 Billion | |
| Brightness (typical) | 400 nits | |
| Contrast Ratio | 5000:1 (Typical) | |
| Viewing Angle | H=178, V=178 | |
| Life Time | 50,000 Hours | |
| Touch System | ||
| Touch Point | 20 for Android, 40 points touch for windows. Touch Accuracy:± 1 mm. Air Gap:0.9 mm | |
| Surface Hardness | Hardness: 7H, 4mm tempered glass, Anti-Glare, Anti-Dust and Anti-Fingerprint Technologies | |
| Others | (IR) Ultra-Fine Touch Technology | |
| Operating System | ||
| System Version | Android 11 | |
| CPU | Quad-core ARM Cortex (A55*4) | |
| GPU | Quad-core ARM Mali G52 (Support 4K UHD) | |
| RAM | 8GB | |
| ROM | 128GB | |
| Connectivity | ||
| HDMI | HDMI-IN 2.0 x 3 (3840x2160 @60Hz) HDMI-OUT 2.0 x1 |
|
| VGA | Yes | |
| PC Audio In | Audio x1 (PC audio in) | |
| Audio out | Audio x1 (PC audio out) | |
| LAN | 2 x RJ45 Gigabyte Ethernet | |
| USB | Type A: USB3.0 x4 (Front x2, Rear x2)； USB2.0 x1 Type B: x2 (Front x1, Rear x1) Type C: Frontx1 (PD65W + DP1.2 + Data USB2.0 + 10M/100M sharing) |
|
| RS232 | RS232: x1 | |
| Others | OPS: x1 (Optional Intel Standard OPS) WiFi: x1 (Optional VB-WIFI-002/VB-WIFI-004/VSB050) |
|
| Physical Specification | ||
| Active Screen Size | 75" | |
| Dimensions | Physical (inch / mm): 1709 x 1020 x 88 mm / 67.3 x 40.2 x 3.5 in Packaging (inch / mm): 1863 x 1140 x 225 mm / 73.3x 44.9 x 8.6 in |
|
| Weight | Net (lb / kg): 104.3lb/47.3kg Gross (lb / kg): 133.5lb/60.55kg |
|
| Power | Voltage: 100-240V AC Consumption: On:106W; Off: ≤ 0.5W |
|
| Others | Wall Mount (VESA): 800x400 Temperature (º C): 0°C to 40°C Humidity: 20% ~ 80% RH non-condensing |
|
| Warranty | ||
| Warranty | 3 Years (Transportation or Conveyance bill will be added for outside Dhaka customers for each service including installation or any warranty issue) | |
